ALUX IDC-261 125kW / 261kWh Liquid-Cooled C&I Energy Storage System

ALUX IDC-261 is a 125kW / 261kWh liquid-cooled C&I energy storage cabinet built on LFP 314Ah cells, rated IP55 with C4 anti-corrosion, and supporting up to 8 units in parallel.

Model	IDC-261
Rated power	125 kW
Rated capacity	261 kWh
Grid connection	Three-phase five-wire, 380/400 Vac
Cell type	LFP 3.2V / 314Ah
Cycle life	≥ 6000 cycles
System efficiency	92%
PCS efficiency	≥ 98.2%
Max. parallel units	8
Protection grade	IP55
Anti-corrosion grade	C4
Installation	Floor-mounted
Dimensions (W × D × H)	1100 × 1400 × 2380 mm
Weight	≤ 3000 kg
